KTM 150 SX [2016-2022] - Cast pistons

VERTEX cast piston for KTM 150 SX 2016-2022

The VERTEX cast piston is designed as a suitable engine component for the KTM 150 SX from the entire 2016-2022 model year range. With its standard compression, it is suitable for replacing the piston in 2-stroke engines.

Technical features

• Piston type: cast
• Material: aluminum
• Piston compression: standard
• Diameter Ø: 57.95 mm
• Letter oversize: B
• Oversize: +0.01
• Bore diameter: 58.00 mm
• Piston rings: 2
• Engine type: 2T

Selection and vehicle assignment

The dimensions support targeted selection when overhauling an engine or replacing the existing piston. The diameter of 57.95 mm, the marking B and the oversize of +0.01 must be compared with the requirements of the motor before ordering.

This VERTEX cast piston is assigned to the KTM 150 SX for the years 2016, 2017, 2018, 2019, 2020, 2021 and 2022. The vehicle assignment applies exclusively to this model and this year of manufacture.

Factual product details

VERTEX specializes in engine components for off-road machines. The piston combines the cast design with an aluminum construction and standard compression. This means that a clearly specified replacement component is available for the 2-stroke engine of the KTM 150 SX mentioned.
